Measure N, P, K, pH, Temperature, Electrical Conductivity, Soil Moisture, and Air conditions with automated pump control. Built by United Software Solutions in Dhaka.
Comprehensive sensor suite with secure cloud and actionable automations.
N, P, K, pH, Soil Temp, EC, Soil Moisture, Air Temp, Humidity, Pressure.
Timestamp every reading for reliable analytics and irrigation scheduling.
Pump turns ON/OFF based on soil moisture threshold with manual override.
Robust EC front‑end with AC excitation to reduce electrode polarization.
Secure APIs, device management, and analytics for farms of any size.
Auth for Admins, Users (Farmers), and Technicians built‑in.
The pump is automatically ON when Soil Moisture is below your threshold. You can toggle automatic mode and simulate moisture with the slider.
// Pseudo‑logic
if (auto && soilMoisture < threshold) pump = ON; else pump = OFF;
// Manual override and safety interlocks can be added as needed.Compact, weather‑resistant enclosure with modular probes.
| Parameter | Symbol | Range (typ.) | Description |
|---|---|---|---|
| Nitrogen | N | 0–500 mg/kg | Soil nutrient level (optical/ion‑selective) |
| Phosphorus | P | 0–200 mg/kg | Soil nutrient level |
| Potassium | K | 0–800 mg/kg | Soil nutrient level |
| pH | pH | 3.0–10.0 | Soil acidity/alkalinity |
| Soil Temperature | Tsoil | −10–85°C | Thermistor/DS18B20 class |
| Electrical Conductivity | EC | 0–20 mS/cm | Salinity proxy via AC excitation |
| Soil Moisture | SM | 0–100% | Capacitive/Time‑domain |
| Air Temperature | Tair | −10–60°C | Onboard temp sensor |
| Air Humidity | RH | 0–100% | Onboard RH sensor |
| Air Pressure | P | 300–1100 hPa | Barometric sensor |
Modular platform supporting devices, sensors, data, and control.
JWT sessions, OAuth, role‑based access (Admin, Farmer, Technician).
Profiles, farms, fields, roles, contact preferences.
Hardware definitions, firmware versions, capabilities.
Provisioning, connectivity, location, status.
Sensor definitions, ranges, units, calibration.
Per‑device sensor instances and health.
Link sensors/devices to farmers.
Ingestion, storage, dashboards, alerts, exports.
Rules for pumps/valves with safety interlocks.
Illustrative block diagram showing AC excitation, instrumentation amplifier, and RMS/ADC stage for reliable EC measurement.
Ready to deploy SoilSensBD or need a custom solution? Send us a message.
